The Powerful Anleon S2 Plus
Introducing the enhanced Anleon S2 Plus, an upgraded version of the renowned stage monitor, now with innovative technology to eliminate interference. This model offers an extended range of over 100 meters, allowing complete freedom of movement. (Note: The previous S2 model has been discontinued, making the S2 Plus the definitive choice, packed with advanced features.)
Unmatched Sound Quality
Experience true audio fidelity. Even at high volumes, the Anleon S2 Plus maintains crystal-clear sound without distortion. Equipped with a revamped transmission antenna, it delivers a steady signal and flawless audio experience, so you can hear every detail with clarity.
Versatile Performance for All Musicians
Designed to meet the needs of various musicians – drummers, keyboardists, guitarists, and vocalists – the Anleon S2 Plus offers flexibility with dual XLR inputs, supporting both mono and stereo modes. Its powerful headphone output ensures you hear your sound accurately, no matter the surrounding noise.
Technical Specifications
- Channels: 36
- Headphone Output: 3.5mm jack
- Power Supply: DC 9-12V/300mA
- Battery Life: Up to 12 hours with 2 AA batteries (alkaline or Ni-MH recommended)
- Range: Up to 50m indoors and over 100m outdoors
- RF Power: 10mW
- Signal-to-Noise Ratio: 80dB(A)
- Modulation: Stereo FM
- Frequency Response: 20Hz to 18KHz
-
Frequency (FCC/CE Certified):
-
EU Version: 670-680 MHz
-
US Version: 526–535 MHz
-
Other Regions: Shipped according to the compliance of the country.
-
Transmitter Features
- Stereo/Mono Mode: Choose stereo for left-right separation or mono for mixed signals.
- Frequency Adjustment: Group and Channel buttons allow for 36 frequency options to ensure clear, interference-free sound.
- Versatile Inputs: XLR, 1/4" (P10), and 3.5mm connections compatible with mixers and audio devices.
- Monitoring Output: 3.5mm jack for real-time audio monitoring on the transmitter.
Receiver Features
- LCD Display: Shows frequency, channel, and battery status.
- Power Indicator: Green for normal operation; red signals low battery.
- Volume and Frequency Control: Easy adjustments for complete control during use.
- Headphone Jack: Clear, comfortable monitoring for professional use.
Care and Recommendations
- Frequency Usage: For multiple transmitters, set unique frequencies and keep at least 1m distance between them.
- Interference Prevention: Avoid using the product near chargers or AC adapters to reduce unwanted noise.
- Battery Recommendations: Avoid lithium AA batteries for the receiver, as they may cause interference. Use alkaline or Ni-MH AA batteries.
Included Items
- Anleon S2 Plus Transmitter
- Transmitter Power Supply
- Anleon S2 Plus Receiver
- Earphones
- Instruction Manual
